Developed with a focus on customer's satisfaction
demanding steering sensitivity, smoothness, durability,
and reliability.
Rigid shaft construction provides smooth and even operation.
Dust seal prevents damage due to debris and and corrosion.
Marol's newly developed Balanced Piston System along with
Marol's unique distribution plate design automatically
adjusts oil flow based on pressure for the best and
smoothest performance.
Forged aluminum body eliminates air pockets.
Max Pressure: 1000 PSI.
Reservoir Capacity: 21.4 cu-in.
Ports: 45˚ flare fitting.
3/4" tapered shaft.
Displacement: 1.83 cu in / revolution.

Developed with a focus on customer's satisfaction
demanding steering sensitivity, smoothness, durability,
and reliability.
Rigid shaft construction provides smooth and even operation.
Dust seal prevents damage due to debris and and corrosion.
Marol's newly developed Balanced Piston System along with
Marol's unique distribution plate design automatically
adjusts oil flow based on pressure for the best and
smoothest performance.
Forged aluminum body eliminates air pockets.
Max Pressure: 1000 PSI.
Reservoir Capacity: 21.4 cu-in.
Ports: 45˚ flare fitting.
3/4" tapered shaft.
Displacement: 2.00 cu in / revolution.

Developed with a focus on customer's satisfaction
demanding steering sensitivity, smoothness, durability,
and reliability.
Rigid shaft construction provides smooth and even operation.
Dust seal prevents damage due to debris and and corrosion.
Marol's newly developed Balanced Piston System along with
Marol's unique distribution plate design automatically
adjusts oil flow based on pressure for the best and
smoothest performance.
Forged aluminum body eliminates air pockets.
Max Pressure: 1000 PSI.
Reservoir Capacity: 21.4 cu-in.
Ports: 45˚ flare fitting.
3/4" tapered shaft.
Displacement: 2.37 cu in / revolution.

Developed with a focus on steering sensitivity, smoothness, durability, and reliability.
Rigid shaft construction provides smooth and even operation.
Dust seal prevents damage due to debris and and corrosion.
Marol's newly developed Balanced Piston System along with a unique distribution plate design automatically adjusts oil flow based on pressure for the best and smoothest performance.
Forged aluminum body eliminates air pockets.

Max Pressure: 1000 PSI.
Reservoir Capacity: 21.4 cu-in.
Ports: 45˚ flare fitting.
3/4" tapered shaft.
Displacement: 1.4 cu in / revolution.

2-6 cubic inch variable delivery helm pump.
This pump features adjustable volume in a compact design.
Adjustments from 2-6 cubic inch per turn is easily accomplished from the outside.
A lock valve installed on the back of the helm pump prevents rudder feedback and also allows installation of multiple control stations.

SeaStar sterndrive steering cylinder.
For non-power assist steering configurations.
Bore: 1.25"
Shaft diameter: .50”
Stroke: 7”
Volume: 8.3 cu. in.
Fitted with O-Ring Boss (ORB) style hose fitting ports.
Seal kit: HS5154

Power assist sterndrive cylinder.
For use with specific Volvo sterndrives.
Bore: 1.25"
Shaft diameter: .50"
Stroke: 8"
Volume: 8.3 cu. in.
Fitted with O-Ring Boss (ORB) style hose fitting ports.
Seal kit: HS5154

Balanced cylinder with engineering features and a simple design make this a very durable cylinder.
Brass tube and piston, end caps and bearings are silicon bronze.
Piston rod is stainless steel and hard chromed.
Nitrile seals provide smooth piston movement.
Bore: 2".

Inboard balanced cylinder.
Replaced Hynautic K-19 cylinder.
Universal mount.
Cylinder equipped with swivel joints at each end.
Shaft diameter: .75"
Stroke: 9"
Volume: 9 cu. in.
Fitted with O-Ring Boss (ORB) style hose fitting ports.
Seal kit: KS-02

Inboard steering cylinder for single and dual rudder
vessels.
Anodized aluminum construction.
Adjustable o-ring sealed ports.
Two axis articulation.
Supplied with bleeder fittings.
Bore: 1.50"
Shaft diameter: .63"
Stroke: 7"
Volume: 10.2 cu. in.
Fitted with O-Ring Boss (ORB) style hose fitting ports.
Seal kit: HS5156
Please note that SeaStar Capilano systems use Dexron II ATF,
not SeaStar steering fluid.

Connector for Glendinning electric controls. Length: 20 feet.

Connector for Glendinning electric controls. 12 volt. Length: 40 feet.

Connector for Glendinning electric controls. Length: 30 feet.

Connector for Glendinning electric controls. Length: 20 feet.

For use with multi-turn hand throttle controls.

Connection kit for Glendinning electric controls.

Foot operated throttle control.
Allows cable entry from any direction 360º in a
horizontal plane and up to 35º in a vertical plane.
When bolted in place it completely seals the
through-floor opening.
Cast aluminum and steel components.
Uses 42C accelerator cable (special order).
Diamond pattern tread on pedal minimizes foot slippage.

Connector for Glendinning electric controls.

Connector for Glendinning electric controls.

Connector for Glendinning electric controls.
For SA2 systems (Yamaha).
Length: 20 feet.

Adjustable control head detent / friction settings.
"Posi-lock" gear lockout.
Selectable station transfer methods.
Station lockout capability.
Adjustable high idle settings.
Control head keypad lights dimmer.
Dual battery inputs.
Audible neutral indicator.

For Waterjet.

Connector for Glendinning electric controls.

Connector for Glendinning electric controls.
Length: 20 feet.

Connection kit for Glendinning electric controls.

For SA2 systems. Length: 100 feet.

For SA2 systems. Length: 120 feet.

For SA2 systems. Length: 80 feet.

For Teleflex CH4400, CH5600 controls. Designed for transmissions supplying a maximum of 5 amps. Right hand. Mounts in port/forward or starboard/aft positions.

Connector for Glendinning electric controls. Length: 20 feet.

Routed king starboard.
For Glendinning electrical control heads, single, dual, and waterjet.
3/4" thick.
Solid plastic construction.

Adjustable control head detent / friction settings. "Posi-lock" gear lockout. Selectable station transfer methods. Station lockout capability. Adjustable high idle settings. Control head keypad lights dimmer. Dual battery inputs. Audible neutral indicator.

Connector for Glendinning electric controls. Length: 35 feet.

Adjustable control head detent / friction settings.
"Posi-lock" gear lockout.
Selectable station transfer methods.
Station lockout capability.
Adjustable high idle settings.
Control head keypad lights dimmer.
Dual battery inputs.
Audible neutral indicator.

Glendinning electromechanical SA 2.
Smart actuators convert the electronic commands that are generated by the control head into specific positions at the engine, stern drive, hydraulic gear, water jet, and trolling valve.
Housed in rugged, corrosion resistant, aluminum enclosures.
Suitable for use with all mechanical engines or transmissions.
Up to 6 station remote control.
12 VDC
Factory programed for Waterjet bucket.
